On February 19, 2019 I have completed my course on programming with Processing. Over the few weeks, I have learned to write functions for Processing, configure parameters, use proper syntax, commenting, and file management followed by weekly challenges where I have developed basic files that are playable. Among these projects was developing a Pong-like game and a Chase Games for which the code is provided here. If you want to try out both codes and play it, please follow the instructions on Processing. Files are here.
Chase Game
Task:
Simple chase game where 3 Chaser objects chase a Player object around the graphics window. The Player object just follows the mouse.
Conditions:
The Chaser objects have 2 special behaviors:
If a chaser collides with the player
it jumps to a random location & the score decrements by 100
Occasionally (0.3% chance in each animation frame)
the chaser jumps on its own without a penalty
Otherwise, the chaser just chases the player as the default behavior
The player’s goal is to avoid the chasers as much as possible.
The score increments by 1 every frame, minus 100 points per collision.
The game runs until the player has been caught 10 times (10 collisions),
whereupon “Game Over” is displayed, and the score at that point becomes
the final score.
This is the code created for the game:
// Global variables
Player p; // 1 player
Chaser c1; // 3 chasers
Chaser c2;
Chaser c3;
float side = 50; // Length of a side of the square used for all logos
int score = 0; // Increments each frame; -100 when player caught
int collisions = 0; // Counts collisions between player & a chaser
int maxCol = 10; // Game over when collisions reaches this value
void setup()
{
size(400, 400);
background(255);
colorMode(HSB); // Easier for random colors
rectMode(CENTER); // Make reference points center instead of corner
// Create the actual objects
p = new Player(side);
c1 = new Chaser(side);
c2 = new Chaser(side);
c3 = new Chaser(side);
}
void draw()
{
background(255);
// If the game is still active
if (collisions < maxCol)
{
// First move everybody
p.move();
c1.move(p);
c2.move(p);
c3.move(p);
// Then display everybody
p.display();
c1.display();
c2.display();
c3.display();
// Increment the score to reflect game still active
score = score + 1;
}
// Else it's game over (game no longer active)
else
{
fill(160, 255, 255);
textSize(40);
text("Game Over", width/2-100, height/2-10);
}
// Display the score in lower left corner of the graphics window
fill(160,255,255);
textSize(20);
text("Score = " + score, 7, height-30);
text("Caught " + collisions + " times", 7, height-7);
}
class Chaser
{
// Attributes
float xLoc; // Location
float yLoc;
float side; // Length of a side of the square logo
float hue; // Hue of the square logo
float speed = 1; // Speed in each dimension, 1 pixel per frame
// Initialize size, generate random hue, start at a random place
Chaser(float s)
{
side = s; // 4
hue = random(255); // 4
jump(); // 4
}
// Handles 3 possible moves: collision with p, random jump, or chase p
// Player p passed in as parameter so that Chaser can see where it is
void move(Player p)
{
// If chaser caught the player (it collided with Player p)
if (collide(p))
{
// Count the collision, assess the penalty, jump to a random place
collisions = collisions + 1; // 8
score = score - 100; // 8
jump(); // 8
}
// Every now and then (0.3% chance), jump anyway with no penalty
else if (random(1000) < 3) // 9
jump(); // 9
// Otherwise Chaser chases Player
else
{
// Move either left
if (p.xLoc < this.xLoc) // 10
this.xLoc = this.xLoc - speed; // 10
// or right
else // 10
this.xLoc = this.xLoc + speed; // 10
// Move either up
if (p.yLoc < this.yLoc) // 11
this.yLoc = this.yLoc - speed; // 11
// or down
else // 11
this.yLoc = this.yLoc + speed; // 11
}
}
// Moves Chaser to random place on graphics window
void jump()
{
xLoc = random(width); // 6
yLoc = random(height); // 6
}
// Collision detector; returns true if Chaser % p overlap, false o/w
boolean collide(Player p)
{
if (abs(p.xLoc - this.xLoc) < side && // 7
abs(p.yLoc - this.yLoc) < side) // 7
return true; // 7
else // 7
return false;
}
// Chaser logo is just a square centered on current location
void display()
{
fill(hue,255,255); // 5
strokeWeight(2); // 5
rect(xLoc,yLoc,side,side); // 5
}
}
class Player
{
// Attributes
float xLoc; // Location
float yLoc;
float side; // Length of a side of the square logo
float hue; // Hue of the square logo
Player(float s)
{
// Start Player in center of screen
xLoc = width/2; // 1
yLoc = height/2; // 1
side = s; // 1
hue = random(255); // 1
}
// Movement just tracks the mouse
void move()
{
xLoc = mouseX; // 3
yLoc = mouseY; // 3
}
// Player is just a square
void display()
{
fill(hue,255,255); // 2
strokeWeight(2); // 2
rect(xLoc,yLoc,side,side); // 2
}
}
